Brand
KYOCERA
Member SKU ID
395112308
AD SKU ID
KYOCERA_Q1_2018_008436
Category
Cutting Tools & Metalworking|Indexable Cutting Tools|Indexable Turning & Boring|Indexable Turning & Profiling|Indexable Turning Insert Holders
Category Child Node
Indexable Turning Insert Holders
ANSI Code
DWLNR164D
Back of Bar to Cutting Edge
1-1/4 in
Cutting Direction
Right Hand
Head Length
0.78 in
Inscribed Circle
3/8 in
Insert Compatibility
WNMG43, WNGG43, WNMM43, WNGA43
Lead Angle
95 deg
Overall Length
6 in
Rake
Negative
Shank Size
1 in W x 1 in H
Tool Holder Style
DWLN
Long Description
KYOCERA Indexable Turning Toolholder, DWLN Tool Holder, 6 in Overall Length, 1 in W x 1 in H Shank, Insert Compatibility: WNMG43, WNGG43, WNMM43, WNGA43, Right Hand Cutting Direction, 3/8 in Inscribed Circle, 1-1/4 in Back of Bar to Cutting Edge, 95 deg Lead Angle, 0.78 in Head Length, ANSI Code: DWLNR164D, Negative Rake
