Brand
SMC
Member SKU ID
395074750
AD SKU ID
CAX_0523_D1PG317_4334
Category
Pipe, Tube & Hose Fittings|Pneumatic Fittings|Pneumatic Connectors
Category Child Node
Pneumatic Connectors
Color
White/Orange
End Style
Push-In
Fitting/Connector Type
Connector
Hex Size
17.46 mm
Material
Brass
Nominal Size
1/4 in x 9/16-18UNF
Pressure Rating
-100 kPa to 1 MPa
Series
KQ2
Temperature Rating
-5 to 60 deg C Air, 0 to 40 deg C Water Operating
Type
Metric Size Union
Long Description
SMC, KQ2E07-00A, Pneumatic Connector, Metric Size Union, Series: KQ2, Fitting/Connector: Connector, 1/4 in x 9/16-18UNF Nominal, Push-In End Style, 17.46 mm Hex, 29.8 mm Length, -100 kPa to 1 MPa Pressure, -5 to 60 deg C Air, 0 to 40 deg C Water Operating, Brass, White/Orange
